XK3201(F701B)

Introduction:

XK3201(F701B)-02 is a professional sorting machine controller. It can automatic online judge and sort the unqualified product of the weight high-accuracy and high-speed.

Main Features:

1, During weighing process, it can set common parameters and view varieties No, actual weight of last scale and various accumulate data, etc;

2,It has three standard sorting weight areas;

3,It has functions of sorting weight, statistics failure, warning ,etc.

4,It has reserve output ports, you can free to select various output functions.

5,it can store the reliable parameters when finished debugging and also can recover the factory parameters.

6,it has 26 pcs switching value output and input ports ( 13 pcs input / 13 pcs output ) and 1 pcs analog output ,and RS485 or RS232 communication.

7,it adopt the international standard MODBUS Protocol, can convenient to connect with touch screen , PLC, upper computer and large screen.

8,it can comparable and compatible with Unipulse (F701C) controller.
